Specification
| Flow Rate (LPM) |
Pressure (Bar) |
Motor H.P. |
RPM (50 Hz) |
Intel Connection (BSP) |
Outlet Connection (BSP) |
| 12 | 90 | 3 | 1450 | 1/2" | 3/8" |
| 60 | 2 | ||||
| 14 | 140 | 5 | 1450 | 1/2" | 3/8" |
| 15 | 250 | 10 | 1450 | 1/2" | 3/8" |
| 180 | 7.5 | ||||
| 21 | 200 | 12.5 | 1450 | 1/2" | 3/8" |
| 180 | 10 | ||||
| 130 | 7.5 | ||||
| 90 | 5 | ||||
| 30 | 190 | 15 | 1450 | 1/2" | 3/8" |
| 155 | 12.5 | ||||
| 125 | 10 | ||||
| 90 | 7.5 | ||||
| 40 | 170 | 20 | 1450 | 3/4" | 1/2" |
| 140 | 15 | ||||
| 95 | 10 | ||||
| 65 | 7.5 | ||||
| 54 | 150 | 25 | 1450 | 3/4" | 1/2" |
| 130 | 20 | ||||
| 100 | 15 | ||||
| 70 | 10 | ||||
| 70 | 150 | 30 | 1450 | 1" | 3/4" |
| 130 | 25 | ||||
| 100 | 20 | ||||
| 80 | 15 | ||||
| 50 | 10 | ||||
| 15 | 500 | 20 | 1450 | 1/2" | 3/8" |
| 17 | 350 | 15 | 1450 | 1/2" | 3/8" |
| 21 | 500 | 30 | 1450 | 1/2" | 3/8" |
| 27 | 290 | 20 | 1450 | 1/2" | 3/8" |
| 30 | 500 | 40 | 1450 | 3/4" | 1/2" |
| Note : All Pumps are suitable for 50Hz Motor also at 50Hz. Flow Rate and required motor HP will be increased by 20% approx. | |||||
